Sketch a circle at the end of the horizontal construction line that is 4.2mm in diameter then draw a concentric circle that is 8.2mm wide. Now we have a staring point for our keychain. Although to be sure you can use the measure feature. By dragging your cursor along the vertical line your mouse will automatically snap to the middle of the line. Next create another construction line perpendicular to the vertical line that connects the left and right sides.
If you do not know, in Fusion360 a construction line is a line that can be used to aid the sketching process, but it is not a part of the sketch itself. We do not want a wonky keychain! Simply, draw a vertical construction line, starting at the bottom and going to the top. Although before we can actually draw out the keychain we must find the middle of the side.
HOW TO MAKE A SPOTIFY CODE KEYCHAIN HOW TO
This step is pretty straight forward if you know how to use Fusion 360, but if not dont worry, like the other steps I will have video above of me creating the keychain if you would like to copy that.įirst, create a new sketch on the top of the model. If you would prefer to leave the model as is then skip this step as nothing in this step is actually essential to the working of this project.
_large.jpg "how to make a spotify code keychain")
Now we will add a small loop at the end for our keychain. Stepping up the different parts of this design creates a great contrast that will make scanning the keychain easier. Finally, extrude the main backplate by 3mm. Like the bar code, select the remainder of the logo and extrude by 2mm.
The first part of the backplate we need to extrude is the backdrop of the logo. Head over to the sketch menu on the left side of your screen and select sketch 1. If your SVG sketch has disappeared after the first extrusion then no worry. Lastly, we have to extrude the backplate. Once you have selected everything, simply hit E on your keyboard and insert 1 into the text bar to make the model extrude by 1mm. If you do not know, in Fusion 360 you can select multiple things at once by holding down ctrl while you click, but before extruding we also have to select the bars inside the Spotify logo. Do not worry if you have trouble finding the discontinuity in the SVG, I have shown above where it was located on mine to hopefully help you locate the gap in yours.ĭesigning the body for the key chain is just about as easy as it gets within Fusion 360 as it consists of only making a couple of extrusions.įirst, we have to go through the tedious process of selecting all the bars that make up the code itself. In Fusion 360 this can be done by pressing L on your keyboard or by clicking the icon in the tool bar at the top then clicking where you want the two endpoints of the line to be.įor mine, I had to repeat this on the bottom bar of the Spotify logo as well. All that must be done to fix this is to draw a line across the gap. Zoom in on the top bar inside the Spotify logo and you will see that it is not continuous. I do not know why Spotify has done this but regardless it is super easy to fix. To see if you have this same issue, try clicking the top bar inside the Spotify logo if just that part highlights then you can skip this step, but if almost the entire logo highlights you have the same problem as me. I do not know if this problem is specific to me or not, but I figured I should make note of it just in case. For some reason, the Spotify logo inside the SVG is not completely finished which makes extruding certain parts difficult.
